特點介紹
產品規格
| Ordering Code | D | F | R | L1 | L2 | L | A | B | H | H1 | Min.Bore Dia. | Holder |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CCR 3 R0.10 L12-40 | 3.0 | 1.4 | 0.1 | 12 | 3.2 | 40 | 90 | 1.2 | 0.8 | 0.60 | 3.1 | SIM 2000 H3 |
| CCR 4 R0.10 L15-50 | 4.0 | 1.9 | 0.1 | 15 | 4.2 | 50 | 90 | 1.6 | 1.0 | 0.80 | 4.1 | SIM 2000 H4 |
| CCR 5 R0.10 L18-50 | 5.0 | 2.4 | 0.1 | 18 | 5.2 | 50 | 90 | 1.8 | 1.2 | 0.90 | 5.1 | SIM 2000 H5 |
| CCR 6 R0.10 L20-50 | 6.0 | 2.9 | 0.1 | 20 | 6.2 | 50 | 90 | 2.0 | 1.5 | 1.00 | 6.1 | SIM 2000 H6 |
| CCR 8 R0.20 L25-60 | 8.0 | 3.9 | 0.2 | 25 | 8.2 | 60 | 90 | 2.5 | 1.8 | 1.25 | 8.1 | SIM 2000 H8 |
| CCR 10 R0.20 L30-75 | 10.0 | 4.9 | 0.2 | 30 | 10.2 | 75 | 90 | 3.0 | 2.0 | 1.50 | 10.1 | SIM 2500 H10 |
